BL-104 Portable Dental X-ray

The device is DC high frequency portable dental x-ray unit, small,light and nearly no radiation.



Tube voltage:60KV

Tube current:1.5mA

Exposure time:0.1-2s

Frequency:30KHz

Tube focus:0.3mm×0.3mm

The distance from skin to cone:130mm

Battery:DC14.8V 6400mAh

Rated power:60VA

Charger input voltage:AC100V-240V±10%

Output voltage:DC16.8V

Ambient temperature:5-40℃

Relative humidity:<75%RH

Net Weight:2.5kg

Gross Weight:4.8kg

Package size:33×31×23cm



1.The device is DC high frequency portable dental x-ray unit, small,light and nearly no radiation.



2.There are manual buttons installed on the surface of shell,operate easily. All of the components are installed in the central PC board. Insulation vacuum and sealed stereotype protection made its brilliant features.



3.The unit mainly suitable for oral pre-treatment diagnosis of internal organization structure and root depth and so on, is indispensable in daily life clinic,especially for dental implant surgery.



4.The battery is durability,it can take about five hundred images after full charged, and it can be charged and discharged for one thousand times in its life.



5.It can be connected with intra-oral digital x-ray imaging system.

parameter

Voltage AC 100V ~ 240V ±10%,
Tube Voltage 60kVP(Fixed)
Tube Currect 1.5mA
Focus Size 0.8mm
Exposure Time 0.01-2 Sec
N.Weight 2.5Kg
G.Weight 5Kg
Dimension 31x31x23CM
Warranty 1 Year
